Place of Origin: | Zhangjiagang, Jiangsu, China |
---|---|
Brand Name: | Sunswell |
Certification: | CE |
Model Number: | BDXGF 72-72-18 |
Minimum Order Quantity: | 1 set |
Price: | USD12,000~2,000,000/SET |
Packaging Details: | PE film with carton box / wood packaging |
Delivery Time: | 60~120 working days |
Payment Terms: | L/C, T/T |
Supply Ability: | 10sets/season |
After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Material: | S/s 304 |
---|---|---|---|
Sanitary Type: | Sanitary Design | Components: | Top Branded Components |
Filling Sacle: | 250ml To 2000ml | Filling Accuracy: | +_2mm |
Certification: | CE, ISO | Trade: | Third Party Guarantee |
Highlight: | SUS304 automatic wine filling machine,robotized automatic wine filling machine,robotized automatic wine bottle filler |
Product Description
Filler Triblock Model | Filler Triblock Model | Filler Triblock Model | Bottle Size | Power | Dimension(mm) | Weight(KG) |
DCGF14-12-5 | 12 | 3000BPH | 200-2000ml | 1.5kw | 2200×1800 × 2000 | 2500 |
DCGF 18-18-6 | 18 | 5000BPH | 200-2000ml | 2.2kw | 2500 × 1800 × 2300 | 3000 |
DCGF 24-24-8 | 24 | 7000BPH | 200-2000ml | 3 kw | 2800 × 2100 × 2300 | 3000 |
DCGF 32-32-10 | 32 | 9000BPH | 200-2000ml | 4 kw | 3500 × 2200 × 2300 | 3500 |
DCGF 40-40-10 | 40 | 12000BPH | 200-2000ml | 4 kw | 4760 × 2080 × 2300 | 4000 |
DCGF 50-50-12 | 50 | 15000BPH | 200-2000ml | 5 kw | 5150 × 3820 × 2700 | 5000 |
DCGF 60-60-15 | 60 | 18000BPH | 200-2000ml | 5 kw | 5300 × 3950 × 2700 | 6500 |
DCGF 72-72-18 | 72 | 20000BPH | 200-2000ml | 6 kw | 6250 × 4773 × 2700 | 7500 |
1. Glass bottle carbonated drink filler Triblock Bottle in-feed system
inlet screw with star-wheel cooperate input the bottle, the suitable bottle is 250ml-2000ml.
2.Glass bottle carbonated drink filler Triblock Rinser
Carbonated drinks filling machine is rotary washing machine, which mainly used for beverage such as beer or carbonated drink, new bottle enter the equipment by star wheel, through gripper and overturn mechanism make bottle down, after washing, it overturn bottle up automatically, then convey to the filling part by star steel, the main material and washing gripper is stainless steel .
3. Glass bottle carbonated drink filler Triblock starwheel
Carbonated drinks filling machine material is plastic star wheel ,the wheel has block bottle protect device.
4. Glass bottle carbonated drink Triblock Filler
A. Filling valve use isobar machinery valve, double vacuum valve, or flow meter counter pressure filler valve, with High speed and big flow, the high accuracy filling valve, filling speed fast, the liquid level is stable.
B. Main drive adopt gear drive independent, high efficiency, small noise, long life, maintenance-free, transducer can control the main motor speed, the machine adopt Variable-frequency variable speed, whole operations area ,engine base is stainless steel contain carbon steel
C. Guide bottle system, simple structure, according to bottle style, can change
D. The whole machine can be controlled automatically by PLC
E. Filling hydraulic material liquid level height adopts liquid level probe control, liquid level steady, filling reliable
F. The machine important parts and electrical elements is import production
G. Filling hydraulic material can be controlled automatically and have CIP washing connector.
5. Glass bottle carbonated drink Triblock Capper
The bottle into the click wheel through the transition card bottleneck Capping Machine. Rotary Capping Machine knife stuck on the only bottleneck location, keeping the bottle upright and prevent rotation. Capping Machine Capping head to remain in the revolution and rotation, under the action of the cam to achieve grasping cap, capping, screw cap, cap off action, complete the capping process. Management Capping Machine is located in the top cover, through drop-cap rail and cover plate connected Capping Machine allocated. Finished bottle through the bottle capping machine sent from the click wheel to the bottle conveyor chains, conveyor chains send out the triple play by the filling machine, into the next process.
Output bottle star wheel part
Nylon wheel and conveyor belt cooperate output the bottle.
Output bottle conveyor belt part
Conveyor motor use frequency control of motor speed, which keep pace with the 3-1 machine. Prevent overturned bottle
Rack part
Rack is welded by high quality carbon steel, Antirust processing and spray surface. The surface is covered by the SUS304.
Electronic control system part
The electronic components like PLC and transducer are from Mitsubishi, Omron, etc., The pneumatic devices are also from international famous brand.
6. Equipment structure
Base
Rotary rinser
Rotary filler
Rotary capper
Bottle infeed and outfeed system
Control
Main configuration
Touch screen: Pro-face
PLC program controller: Mitsubishi
Inverter: Mitsubishi
Photoelectrical controller: Banner
Proximity switch: Turck
Other electrical components: Siemens
Pneumatic component: Festo
Main motor: ABB
