Sunswell Machinery Co., Ltd.
Bottling machines for water, juice, carbonated drinks, milk and oil with 12 years of global market experience and more than 50 countries presence.
| Place of Origin: | Zhangjiagang, Jiangsu, China |
|---|---|
| Brand Name: | Sunswell |
| Certification: | CE |
| Minimum Order Quantity: | 1 set |
| Price: | USD10500~2,000,0/SET |
| Packaging Details: | PE film with carton box / wood packaging |
| Delivery Time: | 60~120 working days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10sets/season |
| Product Name: | Liquid Nitrogen Dosing Machine For Plastic Bottle Juice | Function: | Increase Force Strength,extend Shelflife |
|---|---|---|---|
| Capacity: | 100-500Bottle/min | Control: | Automatic PLC Control |
| Nitrogen Tank: | Nitrogen Container | Application: | Bottles, Aluminum Can |
| Certification: | CE, ISO | ||
| Highlight: | Aluminum liquid nitrogen storage boxes,35L liquid nitrogen storage boxes,35 Liter liquid n2 container |
||
A new generation of stainless steel flip bottle clamp is adopted so that the clamp does not contact the upper part of the thread of the bottle mouth, and a spray head is provided so that the inner wall of the bottle can be rinsed fully without dead corners.
Adopting advanced gravity filling principle, the filling is fast, stable, and accurate.
Adopt magnetic torque type capping head to realize capping and capping. The capping torque is infinitely adjustable, the sealing is tight and reliable, and the cap is not hurt.
Features:
1. Vacuum liquid nitrogen heat insulation pipe ensures the minimum liquid nitrogen consumption.
2.Dosing quantity will plus or minus according different speed feedback to ensure dosing consistency.
3. Front temperature monitoring function is plus or minus liquid nitrogen dosing quantity automatically according to the changes of filling temperature.
This is a important function, and no import device is with this function for now.
4.Advanced dosing valve ensures transport pure and liquid nitrogen.
5. Lowest outlet pressure of dosing valve ensures minimum liquid nitrogen splash.
6. No frost operating condition, 24 hours working without ice blockage with continuous power and liquid nitrogen.
7.Dosing Time could correct to 1MS during operation process.
8.Continuous self-monitoring through alarm indicator
9.Chinese and English for optional in touch screen
10.Small size and simple installation.
11.Precise control liquid nitrogen dosing
12. User could adjust liquid nitrogen dosing easily through micro-adjustment button in touch screen while it is running
13.Could be used in continuous production for twenty-four hours
14. No container No dosing
15. More other speed liquid nitrogen dosing machines for optional to suit other capacity production lines.
Specification:
Rated input voltage: 110VAC-60Hz/220VAC-50Hz +/-10%
Electricity: ≤5A
Humidity: Relative humidity 0%-100%
Working altitude: 3050 meters (10000FT) above the sea level
Noisy: Continuous noise≤78dB(A)
Weight: 32KG
Capacity: Max. Speed could reach to 300 cans per min.
Operating Conditions:
1,Supple of Liquid Nitrogen: Regulate to 0.4-0.8Mpa and connect to vacuum pipe.
2,Compressed Air or Nitrogen: Supply to working of dosing valve. The pipe pressure range is from 0.4Mpa to 0.6Mpa.
3,CGA295 connector between liquid nitrogen tank and vacuum pipe.
Nitrogen tank:
